Brand New – Safety switch, Telemecanique Safety switches XCS, plastic XCSLE, 4NC+2 NO, slow break, 3 entries tapped M20 -230 V
XCSLE3737342 Specifications
Main
range of product
Telemecanique Safety switches XCS
product or component type
Safety switch
component name
XCSLE
design
Slim
material
Plastic
head type
Key operated turret head
contacts type and composition
2 NC + 1 NO
contact operation
Slow-break, break before make
solenoid contacts type and composition
2 NC + 1 NO (slow-break, break before make)
cable entry
3 entries tapped for M20 x 1.5
electromagnet interlocking
Locking on de-energisation and unlocking on energisation of solenoid
[Us] solenoid rated supply voltage
230 V – 15…10 %
cable outer diameter
7…13 mm
electrical connection
Spring terminal, clamping capacity: 1 x 1.5 mm² flexible or solid cable
Spring terminal, clamping capacity: 2 x 0.5 mm² flexible cables with 13 mm bared ends
number of poles
3
locking options description
With interlocking, locking by solenoid
local signalling
1 LED (orange) for actuator withdrawn
1 LED (green) for actuator inserted and locked
signalling circuit voltage
230 V
Complementary
insulation
Double insulated
positive opening
With NC contact
supply voltage type
AC/DC
supply frequency
50/60 Hz
load factor
1
signalling circuit type
AC
mechanical durability
1000000 cycles
minimum actuation speed
0.01 m/s
maximum actuation speed
0.5 m/s
[Ie] rated operational current
0.55 A at 24 V, DC-13, R300 conforming to EN/IEC 60947-5-1
0.75 A at 240 V, AC-15, C300 conforming to EN/IEC 60947-5-1
[Ithe] conventional enclosed thermal current
4 A
maximum load current
<= 15 A
[Ui] rated insulation voltage
300 V conforming to UL 508
300 V conforming to CSA C22.2 No 14
250 V (pollution degree 3) conforming to EN/IEC 60947-1
[Uimp] rated impulse withstand voltage
4 kV conforming to EN/IEC 60947-5-1
minimum switching current
10 mA at 20 °C
minimum switching voltage
17 V
short-circuit protection
4 A cartridge fuse type gG (gl)
6 A type fast blow
maximum actuator forcible withdrawal rtc
1400 N
minimum actuator force for extraction
20 N
resistance to mechanical impact
1.2 J against the partition
4.9 J without partition
maximum operating rate
10 cyc/mn for maximum durability
safety level
Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1
Can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1
Can reach SIL 3 conforming to EN/IEC 61508
safety reliability data
B10d = 5500000 value given for a life time of 20 years limited by mechanical or contact wear
body material
PA (polyamide)
head material
PA (polyamide)
depth
51 mm
height
205 mm
width
44 mm
net weight
0.53 kg
Environment
standards
EN/IEC 62061
EN/IEC 60947-5-1
EN/ISO 13849-1
CSA C22.2 No 14
EN 1088/ISO 14119
EN/IEC 60204-1
UL 508
product certifications
TÜV
UL
CSA
protective treatment
TC
ambient air temperature for operation
-25…60 °C
ambient air temperature for storage
-40…70 °C
vibration resistance
5 gn (f= 10…500 Hz) conforming to IEC 60068-2-6
shock resistance
10 gn for 11 ms conforming to IEC 60068-2-27
electrical shock protection class
Class II conforming to EN/IEC 61140
IP degree of protection
IP66 conforming to EN/IEC 60529 and EN/IEC 60947-5-1
IP67
Packing Units
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Weight
626.0 g
Package 1 Height
5.7 cm
Package 1 width
7.5 cm
Package 1 Length
23 cm
Unit Type of Package 2
S02
Number of Units in Package 2
8
Package 2 Weight
5.688 kg
Package 2 Height
15 cm
Package 2 width
30 cm
Package 2 Length
40 cm
Additional information
Weight
14.5 lbs
Brand
schneider
Condition
New
MPN
XCSLE3737342
Brand
Schneider Electric
